Big Jon Manual Downrigger: A Comprehensive Guide
Big Jon downriggers have a long history, being invented in 1968.
They utilize aircraft-grade aluminum, setting the standard of strength and reliability from our competition.
This guide will explore the Big Jon manual downrigger, including the Gadabout, Runabout, and Big Water models and accessories.
Overview of Big Jon Downriggers
Big Jon Sports has been setting the standard in downriggers since 1968, utilizing aircraft-grade aluminum for unmatched strength and reliability.
Their downriggers are built to last, making them a favorite among anglers.
Big Jon offers a range of manual downrigger models, each designed for specific fishing needs and boat sizes.
From the entry-level Gadabout, perfect for small boats, to the robust Big Water model for larger vessels, Big Jon has a downrigger for every angler.
These manual downriggers are known for their durable construction, smooth operation, and ease of use.
They allow anglers to precisely control their lure depth, increasing their chances of catching fish.
Big Jon’s commitment to quality and innovation has made them a leader in the fishing industry.
Whether you’re a seasoned pro or a weekend angler, a Big Jon downrigger can enhance your fishing experience.
Their products are designed to withstand the rigors of fishing, providing years of reliable service.
Manual Downrigger Models: Gadabout, Runabout, Big Water
Big Jon offers three primary manual downrigger models: Gadabout, Runabout, and Big Water, each tailored to different fishing needs and boat sizes.
The Gadabout is an entry-level downrigger designed for small boats, featuring a single rod holder and a flexible boom to reduce stress on the boat.
The Runabout offers a step up in size and strength, suitable for medium-sized boats and heavier weights.
The Big Water model is the most robust manual downrigger, designed for large boats and demanding fishing conditions.
All three models share Big Jon’s commitment to quality construction and reliable performance.
They are built with high-strength aircraft-grade aluminum for durability and longevity.
Each model features adjustable disc clutches for precise control and smooth operation.
Whether you’re fishing in a small lake or a large body of water, Big Jon has a manual downrigger to meet your needs.
These models provide anglers with the ability to precisely control their lure depth, increasing their chances of success.
Key Features of Big Jon Manual Downriggers
Big Jon manual downriggers boast several key features that set them apart.
A standout is the aircraft-grade aluminum construction, which ensures exceptional durability.
This material withstands harsh marine environments, promising a long service life.
Adjustable disc clutches allow precise control over lowering and raising weights, preventing free-spooling.
Each model comes with a 4×4 mounting plate and hold-down knobs, simplifying installation.
The flexible boom, especially on the Gadabout model, minimizes stress on the boat’s transom.
The integrated single rod holder, standard on many models, adds convenience for anglers.
These downriggers feature a bright, protective anodized finish, enhancing corrosion resistance.
The manual crank operation provides a reliable and straightforward method for depth adjustment.
Models like the Big Water offer increased capacity for heavier weights and deeper fishing.
Big Jon downriggers are designed for ease of use, allowing anglers to focus on fishing.
The robust construction and thoughtful design make them a popular choice among anglers.
These features combine to deliver a dependable and effective downrigger system.
Construction Materials: Aircraft-Grade Aluminum
Big Jon downriggers are renowned for their use of aircraft-grade aluminum in their construction.
This premium material is chosen for its exceptional strength-to-weight ratio.
Aircraft-grade aluminum provides superior durability, ensuring the downrigger can withstand the stresses of regular use.
The material’s inherent corrosion resistance is crucial in marine environments, preventing rust and degradation.
This aluminum alloy maintains structural integrity even under heavy loads and repeated stress.
It contributes to the downrigger’s ability to handle various fishing conditions effectively.
The lightweight nature of aluminum makes the downrigger easier to handle during installation and operation.
This choice of material reflects Big Jon’s commitment to quality and longevity in their products.
The anodized finish further enhances the aluminum’s protective properties, increasing its lifespan.
Aircraft-grade aluminum ensures that Big Jon downriggers offer reliable performance for years to come.
This robust construction provides anglers with confidence in the equipment’s ability to withstand demanding conditions.
The material’s resistance to flexing and bending ensures accurate depth control while trolling.
Big Jon’s use of aircraft-grade aluminum demonstrates their dedication to superior craftsmanship and durability.
Mounting Options and Considerations
When installing a Big Jon manual downrigger, careful consideration of mounting options is essential for optimal performance and usability. Big Jon offers a variety of mounting solutions to accommodate different boat configurations.
The standard 4×4 mounting plate is a common choice, accepting all Big Jon downriggers and rod holders with compatible bases. Transom bars provide a sturdy platform, especially for boats with limited space.
For console steering boats, pedestal seat mounts offer convenient access and integration.
It’s crucial to select a mounting location that allows easy access to the downrigger controls and provides a clear view of the line counter.
Consider the placement of other trolling equipment to ensure everything is easily accessible to all fishing party members.
Before drilling any holes, it’s advisable to get in the boat with your fishing buddies and experiment with different placements.
Ensure that there is no electrical wiring or other obstructions below the mounting surface.
Proper mounting enhances the stability and functionality of the downrigger, contributing to a safer and more enjoyable fishing experience.
Operating a Big Jon Manual Downrigger: Step-by-Step Instructions
Operating a Big Jon manual downrigger is straightforward, but following these steps will ensure efficient and safe use.
First, while the boat is moving at trolling speed, set your fishing reel to free-spool. Apply slight pressure to the spool with your thumb to control the line payout, letting your lure out to the desired distance behind the boat.
Next, take up the slack in your fishing line until there is a bow in your fishing rod. Place your line in the line release, such as the Band Buster.
Lower the cannonball to the desired depth using the manual crank. Keep an eye on the line counter to accurately gauge the depth.
Retighten the reel by turning the crank handle clockwise until the cannonball stops taking out cable.
Hold onto the reel and continue to reel clockwise (about half a turn).
This will secure the reel and prevent the cable from creeping out while you are trolling.
Line Release Systems: Band Buster, Freen Easy Release
Big Jon offers reliable line release systems, including the Band Buster and the Freen Easy Release.
The Band Buster is a simple and effective release that uses a rubber band to secure the fishing line. When a fish strikes, the tension pulls the line from the rubber band, signaling the strike by causing the rod tip to bounce.
The Freen Easy Release is an adjustable tension release favored by charter captains and tournament fishermen. It withstands greater tension from the fishing rod and trips easily from the lightest fish strike.
The Freen Easy Release ensures a solid connection and reliable release.
Selecting the right line release depends on your fishing style and target species. The Band Buster is ideal for lighter setups, while the Freen Easy Release is suited for heavier tackle and more demanding conditions.
Using Big Jon Line Releases
To use the Big Jon Band Buster line release, let your line out to the desired distance behind the boat, then loop a rubber band around the fishing line and back through itself. Securely attach the other end of the rubber band to the Band Buster release.
The Band Buster release signals when a fish strikes, causing the rod tip to bounce.
The Freen Easy Release is an adjustable tension release. To use it, attach the release to the downrigger cable. Then, place your fishing line between the release pads and adjust the tension until it holds the line securely but releases easily when a fish strikes.
The Freen Easy Release is favored by charter captains and tournament fishermen because it withstands greater tension and trips easily. Adjusting the tension on the Freen Easy Release allows for fine-tuning the release sensitivity.
Proper line release setup is crucial for successful downrigger fishing, ensuring that the line releases cleanly and signals strikes effectively.
Maintenance and Care
Maintaining your Big Jon manual downrigger is crucial for ensuring its longevity and optimal performance. Regularly inspect all components for signs of wear, corrosion, or damage. After each use in saltwater, rinse the downrigger thoroughly with fresh water to remove salt deposits.
Lubricate moving parts, such as the spool and handle mechanisms, with a marine-grade lubricant to prevent corrosion and ensure smooth operation. Check the cable regularly for fraying or kinks, and replace it if necessary.
Store the downrigger in a dry, protected location when not in use to prevent exposure to the elements. Periodically clean the exterior surfaces with a mild soap and water solution.
Pay special attention to the line release mechanisms, ensuring they are clean and free from debris. Tighten any loose screws or bolts to maintain stability.
By following these maintenance and care tips, you can extend the life of your Big Jon manual downrigger and enjoy years of reliable service. Proper maintenance also helps prevent costly repairs.
Troubleshooting Common Issues
Even with proper maintenance, you might encounter occasional issues with your Big Jon manual downrigger. One common problem is difficulty reeling the cable in or out. This can often be resolved by lubricating the spool and handle mechanisms.
If the line release is not functioning correctly, check for debris or corrosion and clean it thoroughly. Ensure the tension is properly adjusted for your fishing line.
Another potential issue is cable slippage. Inspect the cable for wear or damage, and replace it if necessary. Make sure the cable is properly wound on the spool.
If the downrigger is difficult to mount or remove, check the mounting hardware for damage or corrosion. Ensure the mounting plate is securely attached to the boat.
In the event of handle slippage, inspect the handle mechanism for wear or damage, and tighten any loose screws. If these steps don’t resolve the issue, consulting the Big Jon schematics and manuals can provide additional guidance.
Accessories and Add-ons
To enhance the functionality and versatility of your Big Jon manual downrigger, a variety of accessories and add-ons are available. Consider adding rod holders to your setup, allowing you to keep your fishing rods secure and easily accessible. Big Jon offers single and multiple rod holder options that can be mounted directly to the downrigger base or boat.
Line releases are essential for precise lure presentation. Big Jon provides a range of line releases, including the Band Buster and Freen Easy Release, to accommodate different fishing styles and line strengths.
For added convenience, explore the option of adding a swivel base, which allows you to rotate the downrigger for optimal positioning. Counter displays are available to show the exact depth.
To protect your downrigger from the elements, consider investing in a protective cover. These covers shield the downrigger from rain, sun, and saltwater, extending its lifespan.
Warranty Information
Big Jon Sports stands behind the quality and durability of its products. Their manual and electric downriggers, as well as manual and electric planer riggers, and auto-stop systems are covered by a Lifetime Warranty.
This warranty provides assurance against defects in materials and workmanship.
To ensure your Big Jon manual downrigger is covered, it is crucial to register your product with Big Jon Sports. You can fill out the Registration Form and mail it to:
Big Jon Sports
11455 US-31 South
Interlochen, MI 49643
The warranty typically covers repair or replacement of defective parts. However, it is important to note that the warranty may not cover damage caused by misuse, neglect, or improper installation.
Before seeking warranty service, it is advisable to consult the troubleshooting section of the owner’s manual or contact Big Jon Sports customer support for assistance.
Big Jon Downrigger Schematics and Manuals
Accessing Big Jon downrigger schematics and manuals is essential for proper maintenance and troubleshooting. These documents provide detailed diagrams of the downrigger components, assembly instructions, and operating procedures.
Big Jon Sports offers a range of manuals for their downrigger models, including the Big Jon Big Water Manual, Big Jon Gadabout Manual, and Big Jon Runabout Manual.
These manuals are often available for free PDF download from the Big Jon Sports website or other online resources.
The schematics illustrate the internal workings of the downrigger, helping users identify and replace worn or damaged parts.
The manuals provide step-by-step instructions for operating the downrigger, including setting the depth, using line releases, and adjusting the clutch.
They also include troubleshooting tips for common issues, such as cable snags or reel malfunctions.
Referencing the schematics and manuals will help ensure the longevity and optimal performance of your Big Jon manual downrigger.
